I8-1000G High Capacity General Waste Incinerator
Contact us for more information
i8-1000G
Download
Data Sheet
Our Flagship General Waste Incinerator
The i8-1000G stands out as our most advanced and high capacity general waste incinerator, designed to handle large volumes of municipal waste efficiently and environmentally. This powerful waste incineration system is ideal for communities, recycling centres, and industries needing to dispose of high volumes of general and solid waste in an effective manner.
Key Features of Our Large Scale General Waste Incinerator
- Impressive burn rate of up to 600 kg per hour
- Large batch sizes for efficient waste processing
- Low emissions performance, among the best in its class
- Enhanced Coretex insulation for optimal thermal efficiency
- Multi-zone temperature control for consistent incineration across the waste spectrum
- Hydraulic doors for easy and safe loading
- SMARTPANEL technology for remote monitoring and diagnostics
Efficient General Waste Disposal Solution
The i8-1000G is at the forefront of combustion technology, providing an effective and sustainable waste disposal solution for various types of general municipal waste. Its high-capacity design makes it suitable for communities and industries processing significant volumes of waste daily, offering a perfect solution as a landfill alternative.
Applications of Our Solid Waste Incinerator
- Landfill Alternative
- Recycling Centres
- Large Camps and Communities (up to 5000 people)
- Industrial Waste Management (up to 8000 kg per day)
- Municipal Waste Incineration
- General Waste Incineration for Various Waste Streams
Advanced Technology for Optimal Waste Incineration
Our large general waste incinerator incorporates cutting-edge features to ensure efficient and environmentally-friendly operation:
- SMARTPANEL Technology: Allows operators to remotely monitor performance and access reports from anywhere in the world.
- High Capacity Burn Process: The advanced design enables an immensely high combustion rate, safely disposing of various general waste types.
- Comprehensive Emission Control: Achieves some of the lowest emissions in its class, ensuring environmental compliance.
- Versatile Waste Handling: Suitable for solid waste, MSW, RDF, furniture, wood, paper, cardboard, and plastics.
Technical Specifictions
Operational Specifications
Combustion Chamber Volume (m3): 8.7m3
Burn Rate*: up to 600kg per hour
Average Fuel Consumption: 40 – 50 ltrs p/h
Operational Temperature: > 850°C
Gas Retention in Secondary Chamber: 2 secs
Temperature Monitoring: Yes
Average ash residue (%): 3%
Thermostatic Device: Yes
Physical Specifications
External Length (mm): 6540mm
External Width (mm): 1840mm
External Height (mm): 6260mm
Door Size (mm): 4000 x 1500mm
Shipping Weight: 21500kg
For reference only, not to be used for installation purposes. * All burn rates are dependant on the calorific value of the waste being incinerate. Atmospheric conditions,fuel (gas/oil) quality, additonal accessories (autoloader, de-asher) can also have a major impact on actual burn rates.
Configuration Choices
Customisation Options
Enhance your general waste incinerator with our range of optional extras:
- Prefabricated shelter
- Skid mounted configuration
- Operators PPE Kit
- Venturi Scrubber
- TLS Loading System
- Small Pollution Control System
- Autoloader
- Heat Exchanger
- Bin Tipper
- Automated Ash Removal
- Touch screen operation
- USB data logger
Why Choose Our Large General Waste Incinerator?
- Expertise: With years of experience in the incineration industry, we provide reliable and efficient solutions for general waste disposal.
- Quality: All our incinerators are hand-built in the UK, ensuring the highest standards of quality and durability.
- Support: Our award-winning design team is always available to offer advice and technical support, ensuring your project gets off the ground without delay.
- Compliance: We can assist you in preparing for planning or permit applications where required, ensuring your general waste incinerator meets all necessary regulations.
- Versatility: The i8-1000G is available as a static or mobile unit, providing flexibility for various waste management scenarios.
Download the i8-1000G Product Brochure
For more detailed information about our heavy duty general waste incinerator, including technical specifications and pricing, download our comprehensive product brochure.
i8-1000G
Download
Data Sheet
Contact Us for a Quote
Interested in our high volume general waste incinerator for efficient waste management? Contact us today for a personalised quote and expert advice on choosing the right incinerator for your waste disposal needs.
We provide a full line of large incinerators for a variety of applications. If you can not find what you are looking for, please contact us and we will assist you with your waste needs.
Optional Extras
Hand-built in the UK
All our incinerators are hand-built in the UK by time-served welders and fabricators. Our award-winning design team are always on hand to offer their advice and technical know-how to ensure we get your project off the ground without delay.
We can also assist you in the preparation for your planning or permit application where required.
